IEEE 802.3i(10Base-T)

IEEE 802.3u(100Base-TX)

IEEE 802.3ab(1000Base-T)

IEEE 802.3ad(Ports aggregation)

IEEE 802.3z(1000Base-SX/LX)

IEEE 802.3x(Flow control)

IEEE 802.1p(Priority)

IEEE 802.1Q(VLAN)

IEEE 802.1d(STP)

IEEE 802.1w(RSTP)

IEEE 802.1s(MSTP)

Port-based VLAN

IEEE802.1Q VLAN

private VLAN

Protocol VLAN

Voice VLAN

MAC VLAN

Common QinQ

Optional QinQ

Flexible QinQ

VLAN Translation

N:1 VLAN Translation

IPv4/IPv6 DHCP Client

Option 82、Option 37/38

IPv4/IPv6 DHCP Snooping、IPv4/IPv6 DHCP Server

STP，RSTP，MSTP

Multiprocess MSTP

LACP load balance

EMVTE（ULPP+ULSM）

G.8032（ERPS）

Loopback detection、VCT、DDM

ULDP

Port rate limit

Broadcast storm control based on message and bytes

Port /MAC binding and MAC filtering

Port based and VLAN based MAC quantity limits

Anti ARP spoofing, anti ARP scanning and ARP binding

DHCP snooping and nd snooping

DAI

Standard IEEE 802.1x, extended IEEE 802.1x, web portal

TACACS+

IGMP v1/v2/v3 snooping、IGMP Fast leave

MLD v1/v2 snooping

Multicast VLAN、 IPv4/IPv6 DCSCM

ACL based flow, VLAN ID, cos, TOS, DSCP

Aggregation policymap

Port based and VLAN based policymap binding

Single speed, single barrel and two colors

Rewriting of DSCP, cos/802.1p priority, TOS and other fields

8 queues per port

SP and WRR queue scheduling algorithms

Matching IP fragment message

IP ACL and match based on source / destination IP, IP protocol type, IP priority, TCP/UDP source and destination port numbers

MAC ACL, and match messages based on source / destination MAC, VLAN ID, cos and other fields

IP+mac combined ACL

Custom ACL

ACL validation based on time period

Port based and VLAN based ACL binding

ACL based redirection

Performing traffic statistics and analysis based on ACL matching

CLI

IPv4/IPv6 http

IPv4/IPv6 ftp/tftp

IPv4/IPv6 sntp/ntp

Radius authentication of Telnet user name and password for ipv4/ipv6

SSH for ipv4/ipv6

Security IP security network management function

Syslog for ipv4/ipv6

SNMP v1/v2c/v3

MIB interface, Trap

RMON 1，2，3，9

Dual img and multi profile

LLDP

Port mirroring and RSPAN

SFlow traffic monitoring

OAM

Mirror sampling
